Building an SDK v0.1.30 – Swaps With Pool Joins & Exits

In the Balancer Smart Order Router (SOR) we try to find the best “path” to trade from one token to another. Until recently we only considered paths that consisted of swaps but the Relayer allows us to combine swaps with other actions like pool joins and exits and this opens up new paths to consider.

Pools, Actions and BPTs

Lets take a look at the humble 80/20 BAL/WETH weighted balancer pool and see some of the associated actions.

A token holder can join a Balancer pool by depositing tokens into it using the joinPool function on the vault. In return they receive a Balancer Pool Token (BPT) that represents their share in this pool. A user can join with a single token or a combination of tokens, as long as the tokens used already exist in the pool.

A BPT holder can exit the pool at anytime by providing the BPT back to the Vault using the exitPool function. And they can exit to one or a combination of the pool tokens.

In the Balancer veSystem users lock the BPT of the 80/20 BAL/WETH weighted balancer pool. This is cool because it ensures that even if a large portion of BAL tokens are locked, there is deep liquidity that can be used for swaps.

A swap against the 80/20 pool with a “normal” token swap would usually just involve swapping tokens that exist in the pool. e.g. swapping BAL to WETH. This can be achieved by calling the `Swap` function on the Balancer Vault.

We also have multihop swaps that chain together swaps across different pools, which in Balancers case is super efficient because of the Vault architeture. This can be achieved by calling the `batchSwap` function on the Vault.

BPT tokens are actually an ERC20 compatible token which means they have the same approve, transfer, balance functionality as any other ERC20. This means it can itself also be a token within another Balancer pool. This opens up a whole world of interesting use cases, like Boosted Pools. Another example is the auraBal stable pool.

Aura

There’s lots of detailed info in the veBal and Aura docs but as a quick summary:

veBAL (vote-escrow BAL) is a vesting and yield system based based on Curves veCRV system. Users lock the 80/20 BPT and gain voting power and protocol rewards.

Aura Finance is a protocol built on top of the Balancer system to provide maximum incentives to Balancer liquidity providers and BAL stakers.

auraBAL is tokenised veBAL and the stable pool consists of auraBal and the 80/20BPT. Now if a user wants to trade auraBal to Weth they can do a multihop swap like:

For larger trades this requires deep liquidity in the BPT/WETH pool, which in the Aura case hasn’t always been available. But there is another potential path, using a pool exit, that can make use of the deep liquidity locked in the 80/20 pool:

With the similar join path also being available:

Updating The Code

So we can see that adding support for these additional paths is definitely useful but it requires some changes to the existing code.

SOR Path Discovery

First we need to adapt the SOR so it considers join/exits as part of a viable path. An elegant and relatively easy to implement solution was suggested by Fernando. Some pools have pre-minted (or phantom) BPT which basically means the pool contains it’s own BPT in its tokens list. This means a swap can be used to trade to or from a pool token to join or exit, respectively. We can make the SOR consider non preminted pools in the same way by artificially adding the BPT to the pool token list.

        if (useBpts) {
            for (const pool of pools) {
                if (
                    pool.poolType === 'Weighted' ||
                    pool.poolType === 'Investment'
                ) {
                    const BptAsToken: SubgraphToken = {
                        address: pool.address,
                        balance: pool.totalShares,
                        decimals: 18,
                        priceRate: '1',
                        weight: '0',
                    };
                    pool.tokens.push(BptAsToken);
                    pool.tokensList.push(pool.address);
                }
            }
        }

We also have to make sure that each pool also has the relevant maths for BPT<>token swaps. Once these are added the SOR can create the relevant paths and will use the existing algorithm to determine the best price.

Call Construction

Paths containing only swaps can be submitted directly to the Vault batchSwap function. A combination of swaps with joins/exits can not – they have to be submitted via the Relayer multicall function. We wanted to try and keep the SOR focused on path finding so we added some helper functions to the SDK.

The first function `someJoinExit checks whether the paths returned from the SOR need to be submitted via the Vault (e.g. swaps only) or the Relayer (swaps and joins/exits). We can do this by checking if any of the hops involve a weighted pool with one of the tokens being the pool bpt. This works on the assumption that the weighted pools are not preminted.

// Use SOR to get swap information
const swapInfo = await sor.getSwaps(tokenIn, tokenOut, ...);
// Checks if path contains join/exit action
const useRelayer = someJoinExit(pools, swapInfo.swaps, swapInfo.tokenAddresses)

The second, buildRelayerCalls, formats the path data into a set of calls that can be submitted to the Relayer multicall function.

First it creates an action for each part of the path – swap, join or exit using getActions:

  // For each 'swap' create a swap/join/exit action
  const actions = getActions(
    swapInfo.tokenIn,
    swapInfo.tokenOut,
    swapInfo.swaps,
    swapInfo.tokenAddresses,
    slippage,
    pools,
    user,
    relayerAddress
  );

which use the isJoin and isExit functions:

// Finds if a swap returned by SOR is a join by checking if tokenOut === poolAddress
export function isJoin(swap: SwapV2, assets: string[]): boolean {
  // token[join]bpt
  const tokenOut = assets[swap.assetOutIndex];
  const poolAddress = getPoolAddress(swap.poolId);
  return tokenOut.toLowerCase() === poolAddress.toLowerCase();
}

// Finds if a swap returned by SOR is an exit by checking if tokenIn === poolAddress
export function isExit(swap: SwapV2, assets: string[]): boolean {
  // bpt[exit]token
  const tokenIn = assets[swap.assetInIndex];
  const poolAddress = getPoolAddress(swap.poolId);
  return tokenIn.toLowerCase() === poolAddress.toLowerCase();
}

Then these actions are ordered and grouped. The first step is to categorize actions into a Join, Middle or Exit as this determines the order the actions can be done:

export function categorizeActions(actions: Actions[]): Actions[] {
  const enterActions: Actions[] = [];
  const exitActions: Actions[] = [];
  const middleActions: Actions[] = [];
  for (const a of actions) {
    if (a.type === ActionType.Exit || a.type === ActionType.Join) {
      // joins/exits with tokenIn can always be done first
      if (a.hasTokenIn) enterActions.push(a);
      // joins/exits with tokenOut (and not tokenIn) can always be done last
      else if (a.hasTokenOut) exitActions.push(a);
      else middleActions.push(a);
    }
    // All other actions will be chained inbetween
    else middleActions.push(a);
  }
  const allActions: Actions[] = [
    ...enterActions,
    ...middleActions,
    ...exitActions,
  ];
  return allActions;
}

The second step is to batch all sequential swaps together. This should minimise gas cost by making use of the batchSwap function. We use the batchSwapActions function to do this:

const orderedActions = batchSwapActions(categorizedActions, assets);

and it is essentially checking if subsequent swaps have the same source/destination – if they do then they can be batched together and the relevant assets and limits arrays are updated.

Each of the ordered actions are encoded to their relevant call data. And finally the Relayer multicall is encoded.

  const callData = balancerRelayerInterface.encodeFunctionData('multicall', [
    calls,
  ]);

And here’s a full example showing how the new functions can be used:

/**
* Example showing how to find a swap for a pair using SOR directly
* - Path only uses swaps: use queryBatchSwap on Vault to see result
* - Path use join/exit: Use SDK functions to build calls to submit tx via Relayer
*/
import dotenv from 'dotenv';
import { BigNumber, parseFixed } from '@ethersproject/bignumber';
import { Wallet } from '@ethersproject/wallet';
import { AddressZero } from '@ethersproject/constants';
import {
BalancerSDK,
Network,
SwapTypes,
someJoinExit,
buildRelayerCalls,
canUseJoinExit,
} from '../src/index';
import { ADDRESSES } from '../src/test/lib/constants';
dotenv.config();
async function getAndProcessSwaps(
balancer: BalancerSDK,
tokenIn: string,
tokenOut: string,
swapType: SwapTypes,
amount: BigNumber,
useJoinExitPaths: boolean
) {
const swapInfo = await balancer.swaps.sor.getSwaps(
tokenIn,
tokenOut,
swapType,
amount,
undefined,
useJoinExitPaths
);
if (swapInfo.returnAmount.isZero()) {
console.log('No Swap');
return;
}
// console.log(swapInfo.swaps);
// console.log(swapInfo.tokenAddresses);
console.log(`Return amount: `, swapInfo.returnAmount.toString());
const pools = balancer.swaps.sor.getPools();
// someJoinExit will check if swaps use joinExit paths which needs additional formatting
if (
useJoinExitPaths &&
someJoinExit(pools, swapInfo.swaps, swapInfo.tokenAddresses)
) {
console.log(`Swaps with join/exit paths. Must submit via Relayer.`);
const key: any = process.env.TRADER_KEY;
const wallet = new Wallet(key, balancer.sor.provider);
const slippage = '50'; // 50 bsp = 0.5%
try {
const relayerCallData = buildRelayerCalls(
swapInfo,
pools,
wallet.address,
balancer.contracts.relayerV3!.address,
balancer.networkConfig.addresses.tokens.wrappedNativeAsset,
slippage,
undefined
);
// Static calling Relayer doesn't return any useful values but will allow confirmation tx is ok
// relayerCallData.data can be used to simulate tx on Tenderly to see token balance change, etc
// console.log(wallet.address);
// console.log(await balancer.sor.provider.getBlockNumber());
// console.log(relayerCallData.data);
const result = await balancer.contracts.relayerV3
?.connect(wallet)
.callStatic.multicall(relayerCallData.rawCalls);
console.log(result);
} catch (err: any) {
// If error we can reprocess without join/exit paths
console.log(`Error Using Join/Exit Paths`, err.reason);
await getAndProcessSwaps(
balancer,
tokenIn!,
tokenOut!,
swapType,
amount,
false
);
}
} else {
console.log(`Swaps via Vault.`);
const userAddress = AddressZero;
const deadline = BigNumber.from(`${Math.ceil(Date.now() / 1000) + 60}`); // 60 seconds from now
const maxSlippage = 50; // 50 bsp = 0.5%
const transactionAttributes = balancer.swaps.buildSwap({
userAddress,
swapInfo,
kind: 0,
deadline,
maxSlippage,
});
const { attributes } = transactionAttributes;
try {
// Simulates a call to `batchSwap`, returning an array of Vault asset deltas.
const deltas = await balancer.contracts.vault.callStatic.queryBatchSwap(
swapType,
swapInfo.swaps,
swapInfo.tokenAddresses,
attributes.funds
);
console.log(deltas.toString());
} catch (err) {
console.log(err);
}
}
}
async function swapExample() {
const network = Network.MAINNET;
const rpcUrl = `https://mainnet.infura.io/v3/${process.env.INFURA}`;
const tokenIn = ADDRESSES[network].WETH.address;
const tokenOut = ADDRESSES[network].auraBal?.address;
const swapType = SwapTypes.SwapExactIn;
const amount = parseFixed('18', 18);
// Currently Relayer only suitable for ExactIn and non-eth swaps
const canUseJoinExitPaths = canUseJoinExit(swapType, tokenIn!, tokenOut!);
const balancer = new BalancerSDK({
network,
rpcUrl,
});
await balancer.swaps.sor.fetchPools();
await getAndProcessSwaps(
balancer,
tokenIn!,
tokenOut!,
swapType,
amount,
canUseJoinExitPaths
);
}
// yarn examples:run ./examples/swapSor.ts
swapExample();
view raw SwapExample.ts hosted with ❤ by GitHub

Photo by Jakob Owens on Unsplash

Building an SDK v0.1.24 – Balancer Relayers and Pool Migrations

What Is A Relayer?

A relayer is a contract that is authorized by the protocol and users to make calls to the Vault on behalf of the users. It can use the sender’s ERC20 vault allowance, internal balance and BPTs on their behalf. Multiple actions (such as exit/join pools, swaps, etc) can be chained together which improves the UX.

For security reasons a Relayer has to be authorised by the Balancer DAO before it can be used (see previous votes for V1 and V2) and even after authorisation each user would still be required to opt into the relayer by submitting an approval transaction or signing a message.

How It Works

Contracts

The Balancer Relayers are composed of two contracts, BalancerRelayer, which is the single point of entry via the multicall function and a library contract, such as the V3 VaultActions, which defines the allowed behaviour of the relayer, for example – VaultActions, LidoWrapping, GaugeActions.

Having the multicall single point of entry prevents reentrancy. The library contract cannot be called directly but the multicall can repeatedly delegatecall into the library code to perform a chain of actions.

Some psuedo code demonstrating how an authorisation, exitPool and swap can be chained and called via the multicall function:

const approval = buildApproval(signature); // setRelayerApproval call
const exitPoolCallData = buildExitPool(poolId, bptAmt); // exitPool call
const swapCallData = buildSwap(); // batchSwap call

const tx = await relayer.multicall([approval, exitPoolCallData, swapCallData]);

Approval

A user has to approve each Relayer before they can use it. To check if a Relayer is approved we can use hasApprovedRelayer on the Vault:

const isApprove = await vault.hasApprovedRelayer(userAddress, relayerAddress)

And we can grant (or revoke) approval for a given relayer by using setRelayerApproval:

const approvalTx = await vault.setRelayerApproval(userAddress, relayerAddress, isApprove);

A Relayer can also be approved by using the setRelayerApproval function from the BaseRelayerLibrary contract. Here a signed authorisation message from the user is passed as an input parameter. This allows an approval to be included at the start of a chain of actions so the user only needs to submit a single transaction creating a better UX.

Chained References

Output References allow the Relayer to store output values from once action which can then be read and used in another action. This allows us to chain together actions. For example we could exit a pool, save the exit amounts of each token to a reference and then do a batchSwap using the references as input amounts for each swap:

An OutputReference consists of an index and a key:

struct OutputReference {
  uint256 index;
  uint256 key;
}

Where the key is the slot the value will be stored at. Index indicates which output amount should be stored. For example if exitPool exits to 3 tokens, DAI (index 0), USDC (1), USDT (2), we would want to use index 0 to store DAI, 1 for USDC, etc.

Example Use Case – Pool Migration

Intro

Balancer aims for the best capital efficiency for LPs so it made sense to offer the option to migrate from the old “staBal3” pool consisting of DAI, USDC and USDT to a new “boosted” stable pool which is more capital efficient because it uses yield bearing assets.

To migrate between these pools would take multiple steps:

  1. unstake from staBal3 gauge → staBalBpt
  2. exitPool from staBal, staBalBpt → DAI, USDC, USDT
  3. join the bb-a-usd2 pool by using batchSwaps
    1. DAI → bbausd2Bpt
    2. USDC → bbausd2Bpt
    3. USDT → bbausd2Bpt
  4. stake bbausd2Bpt in gauge

This would be quite an ordeal for a user to do manually but the Relayer can be used to combine all these actions into a single transaction for the user.

Details

As this is a well defined one off action we decided to add this function to the SDK as a “Zap” under a Migrations module. The user can call the staBal3 function to get all the call data required to call the tx:

{ to, data } = migrations.stabal3(
  userAddress,
  staBal3Amount,
  minBbausd2Out,
  isStaked,
  authorisationSignature
);

Behind the scenes all the call data for each step is crafted and the encoded multicall data is returned:

calls = [
        this.buildSetRelayerApproval(authorisation),
        this.buildWithdraw(userAddress, staBal3Amount),
        this.buildExit(relayer, staBal3Amount),
        this.buildSwap(minBbausd2Out, relayer),
        this.buildDeposit(userAddress),
      ];

const callData = balancerRelayerInterface.encodeFunctionData('multicall', [
      calls,
    ]);

buildSetRelayerApproval allows the user to pass the approval signature if this is their first time using the relayer. This allows us to approve and execute the migration all in a single transaction.

buildWithdraw and buildDeposit handle the gauge actions. The initial call is to withdraw from the staBal gauge and the final call deposits the bbausd2 bpt into the new gauge. We withdraw directly to the Relayer address rather than the users. The gauges return the tokens to the caller, so sending them to the user costs more as we need to manually transfer them:

gauge.withdraw(amount);
// Gauge does not support withdrawing BPT to another address atomically.
// If intended recipient is not the relayer then forward the withdrawn BPT on to the recipient.
if (recipient != address(this)) {
    IERC20 bptToken = gauge.lp_token();
    bptToken.transfer(recipient, amount);
}

Skipping this has two benefits. Firstly it saves gas by avoiding an extra transfer. It also avoids approval issues as now the Relayer is just using its own funds. The final deposit uses the userAddress to send the staked tokens from the Relayer back to the user.

buildExit creates the exitPool call:

// Ask to store exit outputs for batchSwap of exit is used as input to swaps
    const outputReferences = [
      { index: assetOrder.indexOf('DAI'), key: EXIT_DAI },
      { index: assetOrder.indexOf('USDC'), key: EXIT_USDC },
      { index: assetOrder.indexOf('USDT'), key: EXIT_USDT },
    ];

    const callData = Relayer.constructExitCall({
      assets,
      minAmountsOut: ['0', '0', '0'],
      userData,
      toInternalBalance: true,
      poolId: this.addresses.staBal3.id,
      poolKind: 0, // This will always be 0 to match supported Relayer types
      sender,
      recipient: this.addresses.relayer,
      outputReferences,
      exitPoolRequest: {} as ExitPoolRequest,
    });

Output references are used to store the final amounts of each stable token received from the pool. We have precomputed the keys by using the Relayer.toChainedReference helper, like:

const EXIT_DAI = Relayer.toChainedReference('21');
const EXIT_USDC = Relayer.toChainedReference('22');
const EXIT_USDT = Relayer.toChainedReference('23');

These will be used later as inputs to the swaps.

Also of interest is the fact we set toInternalBalance to true. The Balancer V2 vault can accrue ERC20 token balances and keep track of them internally in order to allow extremely gas-efficient transfers and swaps. Exiting to internal balances before the swaps allows us to keep gas costs down.

Because we have previously exited into internal balances we also don’t have to worry about the users having previously approved the Relayer for the tokens:

if (fromInternalBalance) {
// We take as many tokens from Internal Balance as possible: any remaining amounts will be transferred.
uint256 deductedBalance = _decreaseInternalBalance(sender, token, amount, true);
// Because deductedBalance will be always the lesser of the current internal balance
// and the amount to decrease, it is safe to perform unchecked arithmetic.
amount -= deductedBalance;
}

if (amount > 0) {
token.safeTransferFrom(sender, address(this), amount);
}

so the amount will be 0 and the safeTransferFrom call will not be executed.

buildSwap – We can join bbausd2 using a swap thanks to the PhantomBpt concept so here we create a batchSwap call that swaps each stable token to the bbausdBpt and we use the output references from the exitPool call as the input amounts to the swap (which is great as we don’t need to precompute these).

const swaps: BatchSwapStep[] = [
    {
      poolId: this.addresses.linearDai2.id,
      assetInIndex: 1,    // DAI
      assetOutIndex: 2,   // bDAI
      amount: EXIT_DAI.toString(),
      userData: '0x',
    },
    {
      poolId: this.addresses.bbausd2.id,
      assetInIndex: 2,  // bDAI
      assetOutIndex: 0,  // bbausd2
      amount: '0',
      userData: '0x',
    }
    ...
    {
      poolId: this.addresses.linearUsdc2.id,
      assetInIndex: 3,  // USDC
      assetOutIndex: 4, // bUSDC
      amount: EXIT_USDC.toString(),
      userData: '0x',
    },
    ...

In the Relayer VaultActions contract we can see how the swap amounts are set to the value stored in the reference:

for (uint256 i = 0; i < swaps.length; ++i) {
	uint256 amount = swaps[i].amount;
  if (_isChainedReference(amount)) {
	  swaps[i].amount = _getChainedReferenceValue(amount); //e.g. EXIT_DAI
  }
}

And finally (😅) we use another output reference to store the total amount out of bbausd2:

const outputReferences = [{ index: 0, key: SWAP_RESULT_BBAUSD }];

This is used as an input to the final gauge deposit to make sure we stake all the BPT that we have received and that should conclude the migration! You can see this in action on a local fork (yay no real funds required!) by running the integration test here.

Conclusion

The Balancer Relayer is probably not that well known so hopefully this has given a good overview of some of its functionality and flexibility. There’s a lot of room for experimentation and improvement of UX for complex operations so its worth investigating!

Photo by Austrian National Library on Unsplash

Building an SDK 0.1.14 – Adding a Contracts module

Intro

The idea of adding this was to make accessing Balancer contracts easier for users. Normally you need to find and import ABIs and deal with deployment addresses, if we want to make it easy we should just remove that complexity.

Also we are trying to make the main SDK functions return the contract name and functions as part of the attributes returned. This means the user could then just call using something like:

const { contractName, functionName, attributes } = transactionAttributes;

sdk.contracts[contractName][functionName](attributes)

Typechain

Typechain is a package that provides TypeScript bindings for Ethereum contracts. This means functions are statically typed and there is also IDE support which makes things safer and easier to develop against.

Balancer has its own @balancer-labs/typechain package that exposes instances of the commononly used contracts. Adding this to the SDK means we can remove the need to import ABI jsons and we can now create instances of contracts by doing:

import {
    Vault__factory
} from '@balancer-labs/typechain';

Vault__factory.connect(
            this.networkConfig.addresses.contracts.vault,
            provider
        );

which will return a typed Vault contract.

Module

  • Uses BALANCER_NETWORK_CONFIG and config.network to find vault/lidoRelayer/multicall addresses.
  • Added contracts getter to SDK module:
constructor(
        public config: BalancerSdkConfig,
        public sor = new Sor(config),
        public subgraph = new Subgraph(config),
        public pools = new Pools(config),
        public balancerContracts = new Contracts(config, sor.provider)
    ) { ... }

get contracts(): ContractInstances {
        return this.balancerContracts.contracts;
    }

This can then be called like:

const vaultContract = balancer.contracts['vault'];

or:

const vaultContract = balancer.contracts.vault

which will provide typed function refs.

Tradeoffs

One interesting discussion is the trade off of using the Contracts module within other modules. As of now only the Swaps and Multicaller modules using contracts. Using the Contracts module means we either have to pass Contracts in constructor, which adds an extra step if someone want to use modules independently:

const contracts = new Contracts(config)
const swaps = new Swaps(config, contracts)

or we instantiate Contracts within the module – which ends up happening twice if we use the high level SDK function as it is also instantiated there. For now we have decided to use the Typechain factories to instantiate the contracts within the module and will revisit in future if needed.

Photo by Pablo Arroyo on Unsplash

SITIR 11

Market-Protocol Fit – describes some of how Balancer ⚖️ are approaching things. It’s a whole new world!

👨‍🏫 Etsy’s Journey to TypeScript – trying to improve my Typescript as much as possible and there’s some interesting stuff here.

⏱️ Just-in-time Liquidity – pretty interesting MEV attack. Random idea – could this be a type of exchange where users get a better price and “LPs” rebalance?

Cool tool 🧰: eth-sdk, provide the address of the contract you want to interact with and it will pull down abi from Etherscan API and create Typescript and Ethers instances.

📺 How to make hard choices – worth a watch. Drifting…

This guy has some awesome NFT displays and a guide! 🖼️

️️️⏪ Replaying a transaction (from its hash ️️️) to get a revert reason. (Needs an archive node)

Flickr Engineering Team Vision & Guiding Principles – some good examples for how I should approach things. ✔️

🎵 Watched some of the Beatles Get Back doc and it showed how powerful it is when people truly work together. Fred Wilson said it better than I can!

💹 Ming Zhao on Twitter has some really good TLDR threads on more advanced finance stuff. Like this 12 Crypto Hedge Fund Trading Strategies.

Damn – Cobie is fast becoming one of my crypto heroes and his Substack is really good! 🔥

6 figures a day 🤑 selling Excel courses – meet Miss Excel

🍴 Tenderly forking end point – super useful for building/testing.

The Nothingness Of Money – no one knows where the finish line is, so be present and enjoy the journey! 🧘

🦄 Dune is one of the companies I always had a feeling would do well – from nobody to unicorn in 3 years shares their inspiring story so far.

The Crazy Idea Framework 🤪 sounds like an interesting one to try for investing.

How People Think, Morgan Housel 🧙‍♂️ is one of the best and this feels like it should be read every week as a reminder!

🌺 Bloom Filters are cool! Here’s an interesting thread on how Lens protocol is using them.

Pretty interesting negotiation advice – already feel like I’m constantly negotating with my 2 year old 👼

😎 This post about Alan Kay and his inventions is just really cool.

Quality of life vs quantity – makes you think 🤔

Death by PowerPoint: the slide that killed seven people – puts boring PowerPoints into a whole new perspective. 😥

😨 Shadow of the Sun – this is just brutal. Some of the descriptions are my idea of hell I think.

Photo by Ving N on Unsplash

Node Performance Measurement

I was working on optimising a javascript maths function and wanted to compare the performance of different versions of the code. Initially I had some difficulty because I was approaching it incorrectly so I wanted to make a note for future reference.

First mistake – only using a small number of runs. I was comparing the two different functions with a very small iteration amount. This was leading to weird results where each iteration would get faster even though it was actually the same code running. I think this was related to some compiler optimisation or something. Anyway, after reading JavaScript Compiler Optimization Techniques, I changed to a very large number of runs. This made the results much more consistent.

Second mistake – using perf_hooks incorrectly. From the same blog I also found out the nice way to use perf_hooks to measure the performance:`

import { performance, PerformanceObserver } from 'perf_hooks';

let iterations = 1_000_000;

performance.mark('start');
while (iterations--) {
    StableMath._calcOutGivenIn(
        poolPairDataBigInt.amp,
        poolPairDataBigInt.balances,
        poolPairDataBigInt.tokenIndexIn,
        poolPairDataBigInt.tokenIndexOut,
        amt,
        poolPairDataBigInt.fee
    );
}
performance.mark('end');

iterations = 1_000_000;

performance.mark('startSecond');
const invariant = StableMath._calculateInvariant(
    poolPairDataBigInt.amp,
    poolPairDataBigInt.balances,
    true
);
while (iterations--) {
    StableMath._calcOutGivenInNoInv(
        poolPairDataBigInt.amp,
        poolPairDataBigInt.balances,
        poolPairDataBigInt.tokenIndexIn,
        poolPairDataBigInt.tokenIndexOut,
        amt,
        poolPairDataBigInt.fee,
        invariant
    );
}
performance.mark('endSecond');

const obs = new PerformanceObserver((list, observer) => {
    console.log(list.getEntries()); // [0]);
    performance.clearMarks();
    observer.disconnect();
});
obs.observe({ entryTypes: ['measure'] });

performance.measure('NoOptimisation', 'start', 'end');
performance.measure('WithOptimisation', 'startSecond', 'endSecond');

Which results in an output like:

[
  PerformanceMeasure {
    name: 'NoOptimisation',
    entryType: 'measure',
    startTime: 2369.287365913391,
    duration: 35891.85489702225,
    detail: null
  },
  PerformanceMeasure {
    name: 'WithOptimisation',
    entryType: 'measure',
    startTime: 38261.19673395157,
    duration: 18529.005373954773,
    detail: null
  }
]

As well as having a nice output it also shows my optimisation worked pretty nicely!

Photo by Saffu on Unsplash

Forking Brilliant

Houston We Have A Problem

I want to check that a transaction will work on mainnet for an account I don’t control. In this case it’s for a large LP in the Balancer staBal3 pool and I want to check they could successfully migrates their staBal3 to the new bb-a-USD using a Relayer multicall with the params created by the SDK.

This definitely isn’t the most elegant way of doing things but it works!

Whale Hunting

The first thing I need to do is to find a large staBal3 LP account and figure out their BPT balance. I can use the Balancer Subgraph to query account pool shares for the staBal3 pool. Query looks like:

query MyQuery {
  poolShares(where: {poolId: "0x06df3b2bbb68adc8b0e302443692037ed9f91b42000000000000000000000063"}, orderBy: balance, orderDirection: desc) {
    id
    balance
  }
}

I then manually worked my way down the list of addresses until I found one that was an EOA: https://etherscan.io/address/0x4086e3e1e99a563989a9390facff553a4f29b6ee and at the time of investiagation this had a BPT balance of: 10205792.037653741889318463 (a cool $10.28mil!).

Exit Stage Right

The SDK helper function (relayer.exitPoolAndBatchSwap) that creates the call data requires an input param of expectedAmountsOut which in this case represents the DAI/USDC/USDT amounts out when exiting the staBal3 pool. Because I don’t have the maths required for this exposed yet a quick way to get this is to see the output amounts using Withdraw in the UI. There’s a very nice tool that allows us to simulate this when we don’t have control of the account of interest: https://www.impersonator.xyz/

Now that I’ve got all the info required I can generate the call data by using the helper function. In this case we get an array of call data which represent an exitPool call on staBal3 followed by a batchSwap that swaps the stables received from the exit to the bb-a-USD BPT.

The Magic

Tenderly has lots of useful features including Transaction Simulations. To begin I tried simulating the multicall call on the Mainnet Relayer but the tx failed highlighting a new issue – the account hasn’t approved the Balancer Relayer. To get around this I can use a Tenderly Fork – “Forks allow you to chain simulation and test out complex scenarios with live on-chain data”. This is cool because I can now fork the chain make an approval on the relayer from the account which then allows me to succesfully simulate the multicall!

Photo by Joel Muniz on Unsplash

Building an SDK 0.1.0 – Improving SOR data sourcing

Intro

A big focus for Balancer Labs this year is to make it really easy to build on top of the protocol. To aid in that we’re putting together the `@balancer-labs/sdk npm package. As the current lead in this project I thought I’d try and document some of the work to help keep track of the changes, thought process and learning along the way. It’ll also be useful as a reminder of what’s going on!

SOR v2

Some background

We already have the Smart Order Router (@balancer-labs/sor), a package that devs can use to source the optimal routing for a swap using Balancer liquidity. It’s used in Balancers front-end and other projects like Copper and is a solver for Gnosis BGP. It’s also used in the Beethoven front-end (a Balancer friendly fork on Fantom, cool project and team and worth checking out).

The SOR is also used and exposed by the SDK. It’s core to making swaps accesible but is also used for joining/exiting Boosted Pools which uses PhantomBpt and swaps (a topic for another time I think!).

SOR Data

The diagram below shows some of the core parts of the SOR v2.

SOR v2

To choose the optimal routes for a swap the SOR needs information about the Balancer pools and the price of assets. And as we can see from the diagram the sourcing of this data is currently very tightly coupled to the SOR. Pools data is retrieved from the Subgraph and updated with on-chain balances using a multicall. And asset pricing is retrieved from CoinGecko.

Recently Beethoven experienced a pretty large growth spurt and found there were some major issues retrieving data from the Subgraph. They also correctly pointed out that CoinGecko doesn’t always have the asset pricing (especially on Fantom) and this information could be available from other sources.

After some discussions with Daniel (a very helpful dev from Beethoven) it was agreed that a good approach would be to refactor the SOR to create composability of data fetching so the user is able to have more control over where data is coming from. With this approach, the SOR doesn’t need to know anything about CoinGecko or the Subgraph and the data could now come from anywhere (database, cache, on chain, etc.), and as long as it implements the interface, the SOR will work properly.

Changes – SOR v3

I came back from Christmas break and Daniel had made all the changes – friendly forks for the win 💪! The interface changes are breaking but the improvements are worth it – SOR 3.0.0.

Config

The goal was to remove all the chain specific config from the SOR and pass it in as a constructor parameter. This helps to avoid non-scalable hard-coded values and encorages a single source of truth. It also gives more flexibility for the variables and makes the code easier to test.

There is now the SorConfig type:

export interface SorConfig {
    chainId: number;
    weth: string;
    vault: string;
    staBal3Pool?: { id: string; address: string };
    wethStaBal3?: { id: string; address: string };
    usdcConnectingPool?: { id: string; usdc: string };
}

Pool Data

The goal here is to allow for flexibility in defining where the pool data is fetched from. We define a generic PoolDataService that has a single function getPools, which serves as a generic interface for fetching pool data. This allows allow for any number of custom services to be used without having to change anything in the SOR or SDK.

export interface PoolDataService {
    getPools(): Promise<SubgraphPoolBase[]>;
}

Approaching it this way means all the Subgraph and on-chain/multicall fetching logic is removed from the SOR. These will be added to the Balancer SDK as stand-alone services. But as a simple example this is a PoolDataService that retrieves data from Subgraph:

export class SubgraphPoolDataService implements PoolDataService {
    constructor(
        private readonly chainId: number,
        private readonly subgraphUrl: string
    ) {}

    public async getPools(): Promise<SubgraphPoolBase[]> {
        const response = await fetch(this.subgraphUrl, {
            method: 'POST',
            headers: {
                Accept: 'application/json',
                'Content-Type': 'application/json',
            },
            body: JSON.stringify({ query: Query[this.chainId] }),
        });

        const { data } = await response.json();

        return data.pools ?? [];
    }
}

Asset Pricing

The goal here is to allow for flexibility in defining where token prices are fetched from. We define a generic TokenPriceService that has a single function getNativeAssetPriceInToken. Similar to the PoolDataService this offers flexibility in the service that can be used, i.e. CoingeckoTokenPriceService or SubgraphTokenPriceService.

export interface TokenPriceService {
    /**
     * This should return the price of the native asset (ETH) in the token defined by tokenAddress.
     * Example: BAL = $20 USD, ETH = $4,000 USD, then 1 ETH = 200 BAL. This function would return 200.
     * @param tokenAddress
     */
    getNativeAssetPriceInToken(tokenAddress: string): Promise<string>;
}

All the CoinGecko code is removed from the SOR (to be added to SDK). An example TokenPriceService using CoinGecko:

export class CoingeckoTokenPriceService implements TokenPriceService {
    constructor(private readonly chainId: number) {}

    public async getNativeAssetPriceInToken(
        tokenAddress: string
    ): Promise<string> {
        const ethPerToken = await this.getTokenPriceInNativeAsset(tokenAddress);

        // We get the price of token in terms of ETH
        // We want the price of 1 ETH in terms of the token base units
        return `${1 / parseFloat(ethPerToken)}`;
    }

    /**
     * @dev Assumes that the native asset has 18 decimals
     * @param tokenAddress - the address of the token contract
     * @returns the price of 1 ETH in terms of the token base units
     */
    async getTokenPriceInNativeAsset(tokenAddress: string): Promise<string> {
        const endpoint = `https://api.coingecko.com/api/v3/simple/token_price/${this.platformId}?contract_addresses=${tokenAddress}&vs_currencies=${this.nativeAssetId}`;

        const response = await fetch(endpoint, {
            headers: {
                Accept: 'application/json',
                'Content-Type': 'application/json',
            },
        });

        const data = await response.json();

        if (
            data[tokenAddress.toLowerCase()][this.nativeAssetId] === undefined
        ) {
            throw Error('No price returned from Coingecko');
        }

        return data[tokenAddress.toLowerCase()][this.nativeAssetId];
    }

    private get platformId(): string {
        switch (this.chainId) {
            case 1:
                return 'ethereum';
            case 42:
                return 'ethereum';
            case 137:
                return 'polygon-pos';
            case 42161:
                return 'arbitrum-one';
        }

        return '2';
    }

    private get nativeAssetId(): string {
        switch (this.chainId) {
            case 1:
                return 'eth';
            case 42:
                return 'eth';
            case 137:
                return '';
            case 42161:
                return 'eth';
        }

        return '';
    }
}

Final Outcome

After the changes the updated diagram shows how the SOR is more focused and less opinionated:

The plan for the Balancer front-end is to move away from using the SOR directly and use it via the SDK package. The SDK will have the data fetching functionality as serparate services (which can be used independetly for fetching pools, etc) and these will be passed to the SOR when the SDK is instantiated. BUT it’s also possible to use the SOR independendtly as shown in this swapExample.

This was a large and breaking change but with the continued issues with Subgraph and more teams using the SOR/SDK it was a neccessary upgrade. Many thanks to Daniel from the Beethoven team for pushing this through!

SITIR 10

A from-scratch tour of Bitcoin in Python – create, digitally sign, and broadcast a Bitcoin transaction in pure Python, from scratch, and with zero dependencies.

Computer scientist Leonard Adleman on – Choosing the right problem to work on 🧘

🧠 Booby Trapping the Ethereum Blockchain – Samczun again, amazing.

How to Die with Zero – This book is not about making your money grow — it’s about making your life grow 🤔

🧰 Local ERC20 Balance Manipulation (with HardHat) – unlocks the ability to manipulate the state of any forked contract.

Capitalism: You Wouldn’t Trade it for Anything – Interesting thoughts 💡

🏋️‍♂️ How Much Ya Bench? Strength Benchmarks for Men

Automating Code Changes via GitHub Actions Making Pull Requests – Could be handy some time 🦿

🛠️ Smok – Contract mocking in JavaScript

🤪 Pretty wacky story about Ian Freeman that’s worth a read

Eye opening look at defi “bluechip” performance over last year, denominated in ETH 😲

🐛 Debugging the Comp hack with Dapptools

Punk6529 on Making It 😎

Thought provoking reasons to retire as soon as possible from this post by esimoney 💔

Unbeatable Video Games – I like this and it echoes thoughts I had after watching Competitive Dog Grooming and I kind of wish I had something like that 💭

A depth year is a cool idea! 👷

Photo by Kelly Sikkema on Unsplash

You Can Do It!

At Balancer we recently finished a pretty major release and it was probably the most stressful release I’ve been involved in with there so far. I wanted to write this as a kind of log of a cool thing I helped build but also as a reminder that its possible to get through the tough times and come succesfully out the other side!

The release was actually two pretty major things – first there was the launch of Balancers MetaStable pools, and second was a partnership with Lido. MetaStable pools allow pools of tokens with highly correlated prices, for example cDAI and DAI and Lido were making use of a MetaStable pool to launch an incentivised WETH/wstETH pool. We integrated Lido pretty deeply and the goal was to support trades in stETH by using a Relayer contract to wrap/unwrap automatically, this meant we also had to take into account the stETH/wstETH exchange rates for calcualtions and display. We also wanted to make use of the deep WETH/Stable liquidity Balancer has and allow stable <> Lido trades, this was a slight issue because it involved a two hop trade (i.e. USDC > DAI > WETH > wstETH) which the SOR doesn’t currently support so we had to add static routes for those.

There was a lot going on across all the different teams in Balancer with some fairly tight/strict deadlines. At the time (and actually still now) there’s no Product Manager at Balancer so there wasn’t really someone managing the project. Because of this it very much felt like cat herding and some of the communication could have been better. Also things were changing a lot quite close to the deadline which made things pretty stressful for someone like me who likes to try and get things done early! The last mistake was the deployments of everything happened over the weekend for a Monday launch which wasn’t ideal. These are all things that are being addressed now that we’ve had some retrospectives – Balancer always seem good at continuously trying to improve.

A lot of this probably won’t make a great deal of sense but some of the things that I touched during the work:

  • SOR Hardcoded paths
  • SOR MarketSP support
  • Swap amount via query
  • Stable pool issues due to invariant
  • Subgraph update and rollout
  • Kovan test deployment:
    • stETH + wstETH token on Kovan
    • Faucet for wstETH
    • Correct pools
    • Relayer
  • Relayer – authorisation and approval debug
  • Relayer join/exits being canned after I spent time on them,
  • Limits on front-end
  • Front-end using correct stETH/wstETH exchange

And there was a whole bunch of other stuff being worked on across other teams.

And at the end of it all we made it! The launch went ahead smoothly and on time. The Lido pools are already some of the largest in the Balancer Vault and there haven’t been any major issues so far. I certainly learned a lot and enjoyed working with some team members I haven’t been involved with before. And although it was really stressful and tough at times, the old cliche of breaking down something large into smaller pieces and just working through them is true. Phew!

Update:

Kristen, the Balancer COO, posted a tweet about Impostor Syndrome from Just Kan that I thought was pretty pertinent.

“You will always feel like you are drowning. Even when you are succeeding, it feels like you are drowning because you are constantly being forced to do something new that you haven’t had experience in. While figuring this stuff out on the fly, you’re going to feel like you’re failing and that you’re an impostor.”

Photo by Ava Sol on Unsplash

SITIR 9

😽 Example of a Flashbot bundle to rescure a cryptokitty from a compromised wallet.

💡 Another UMA post – they keep posting interesting use cases that I’m always interested to dive into but never have the time to do (I think this is maybe part of their problem). Keeping it logged here as a bookmark!

Really good advice (especially given the latest massive correction and volatility) from Ari Paul 🦉

I rarely have good ideas. To overcome this limitation, I think about one topic (like habits) for an unreasonable amount of time. Then, I revise, revise, revise until only the best stuff remains. It’s slow, but it works. You can either be a genius or you can be patient.

James Clear

📷 Using a camera and TinyML to read a physical meter and convert it into an API.

🔧 Multicall pattern in Solidity using Delegatecall. Tweet from Austin.

👨‍💻 Interesting details about running your own ETH node in the cloud.

😎 And this seems like something useful you could do with a node – eth_call any contract with an arbitrary code to access storage values without corresponding public views.

👮 Why I Did Not Go To Jail by Ben Horowitz – just a good example of doing the right, difficult thing.

⚖️ A cool write up explaining what we’ve been working on at Balancer for V2.

⭐ Not sure if this description of path to fame and fortune within Ethereum is meant to have a negative connotation but I’m on step 2!

🤣 Marshawn Lynch at Applebee’s – funny! But I like this guys attitude toward money from what I’ve read.

🧰 What problems do people solve with strace? – Could be handy some day.

🧠 This was cool – post by samczsun giving a guided walkthrough for swap, the hardest challenge in Paradigm CTF 2021.

🧮 I like what @adlrocha is doing with the Improving my math intuition series and the first part about Network Applications of Bloom Filters was really interesting.

Bitcoin is Dead! Quite a fun site, particularly at this time.

You’re not that good. Yet. 🧘‍♂️

👏 This was a nice tweet storm about Balancer V2 and how Coinbase employees were going to invest in it. Not sure it came true but the V2 stuff is!

📺 zkPorter seems like a novel tech and this explainer video was good.

💃 Taylor Swift and NFTS, what’s not to like?

If working at Balancer ever gets non-fun then I imagine I’d like to do something like this. Also cool way to recruit. 🤔

👴🏼 How to Keep Your Edge as You Get Older – good podcast with ideas for me!

🔩 Etherscan & Tx Logs – some nice detail on how to walk these for info.

🏦 Eth staking and Warren Buffet. It’s all about where you stand.

🤯 Uncovering a Four Year Old Bug. A glimpse into how samczsuns brain works hunting down a bug.

🔌 Teardown of a PC power supply – always wanted to get a breakdown of a PSU and this is a really accessible one. Better than the majority of my Uni lectures!!

Photo by Ben White on Unsplash
